Current profitability
The estimated profitability for the Intel Arc B580 is currently $0.13 per day before accounting for electricity costs. With an electricity rate of $0.10 per kWh, the estimated daily profit would be around $-0.17.
Where to buy
Disclaimer: This is promotional content. We may receive compensation.
Estimates
Specifications
Historical
Arc B580
Information
PlatformConsumer
ArchitectureBattlemage
GenerationArc B
InterfacePCIe 4.0 x8
Arc B580
Core
NameBMG-G21
FoundryTSMC
Process Node5 nm
Transistors19600 million
Die Size272 mm²
Density72.1 /mm²
Arc B580
GPU Core Config
Cores2560
TMUs160
ROPs80
Tensor Cores160
RT Cores20
Arc B580
Memory
TechnologyGDDR6
Size12 GB
Bus192 bit
Bandwidth456 GB/s
Speed19 Gbps
Arc B580
Clocks
Base clock2670 MHz
Boost Clock2670 MHz
Memory Clock2375 MHz
Arc B580
Power
8-pin1
TDP190 w
Recommended PSU600 w
Arc B580
Display
DisplayPort3
DisplayPort Version2.1
HDMI1
HDMI Version2.1a
HDCP2.3
Resolution7680 x 4320
Arc B580
Dimensions
Slots2
Length272 mm
Height115 mm
Width40 mm
Weight779 g
Models
GPU▲Price▲Shop▲Slots▲
ASRock Intel Arc B580 Challenger OC
B580 CL 12GO
$299.99
2
ASRock Intel Arc B580 Steel Legend OC
$309.99
2.6
Intel Arc B580 Limited Edition
$376.30
2
Sparkle Intel Arc B580 TITAN OC
SB580T-12GOC
$369.99
2.2
Sparkle Intel Arc B580 TITAN Nox OC
SB580TB-12GOC
2.2
Sparkle Intel Arc B580 ROC Luna OC Ultra
SB580RW-12GOC
2.2
Sparkle Intel Arc B580 TITAN Luna OC
SB580TW-12GOC
2.2
Sparkle Intel Arc B580 GUARDIAN
SB580G-12G
$424.39
2.2
GUNNIR Intel Arc B580 Photon OC
$380.00
2.6
Acer Nitro Intel Arc B580 OC
$414.99
2
