| Platform | Consumer |
| Architecture | Ada Lovelace |
| Generation | GeForce RTX 40 |
| Interface | PCIe 4.0 x16 |
| Max temperature | 90 C |
| Name | AD106 |
| Foundry | TSMC |
| Process Node | 5 nm |
| Transistors | 22900 million |
| Die Size | 188 mm² |
| Density | 121.8 /mm² |
| Cores | 4352 |
| TMUs | 136 |
| ROPs | 48 |
| SMs | 34 |
| Tensor Cores | 136 |
| RT Cores | 136 |
| Technology | GDDR6 |
| Size | 16 GB |
| Bus | 128 bit |
| Bandwidth | 288 GB/s |
| Speed | 18 Gbps |
| Base clock | 2310 MHz |
| Boost Clock | 2535 MHz |
| Memory Clock | 2250 MHz |
| TDP | 160 w |
| Recommended PSU | 550 w |
| DisplayPort | 3 |
| HDMI | 1 |
| Monitors | 4 |
| FP16 Tensor | 73.98 TFLOPS |
| FP32 | 20.65 TFLOPS |
| FP64 | 0.32 TFLOPS |
